Pahlen Inlet Nozzle Marine

Pahlen Inlet Nozzle Marine

This inlet nozzle stands out with its round, compact and elegant design, accentuated by a highly polished front that contributes to an aesthetically appealing integration into the pool environment.

The new inlet from Pahlen is constructed with a unique and innovative design that includes two oval nozzles. This configuration is specifically designed to deliver a longer throw length of the water, which is crucial for effective water movement. The two nozzles are positioned with 6 degrees between them, which significantly improves circulation in the pool. This improved circulation contributes to a more even distribution of chemicals and more effective cleaning. The nozzle can be installed both horizontally and vertically, providing flexibility depending on the pool's specific installation requirements, and its direction can be adjusted by ±11° for optimal adaptation.

To ensure optimal water purification and distribution, it is recommended to install two or more inlet nozzles, depending on the size of your pool. This configuration maximizes the efficiency of the water flow and thus the purification of the water throughout the pool.

The recommended maximum flow for this inlet nozzle is 6 m³/h.

Features

• • Made of stainless acid-resistant steel for superior durability and corrosion resistance, making the Pahlen Inlet Nozzle Marine a robust choice.
  • Equipped with an adjustable nozzle with a diameter of Ø26 mm.
  • Designed for easy mounting in all types of pools, which underscores its versatility and wide range of applications.
